Underwater Measurement Robot
ROVINS V3

Youngpoong's unique underwater exploration
and inspection robot

Products＿＿＿

Underwater Measurement Robot
ROVINS V3

Youngpoong's unique underwater exploration and inspection robot

 Underwater robot for suction tasks(Light Workclass)

ROVINS-V3

Robots that clean underwater debris and trash via suction hoses

• Cleans underwater floats and waste through a suction hose mounted on the device

• Maintains the seafloor altitude and prevents collisions using 360-degree ultrasonic sensors List

ROVINS = ROV(Remotely Operated Vehicle) + INSPECTION


Features

Underwater Ultrasonic
Collision Avoidance Sensor

Maintains the seafloor altitude and prevents collisions using 360-degree ultrasonic sensors

 Suction Hose

A robot cleaning underwater floats and waste
through a suction hose mounted on the device

Front Camera

Front-loaded camera ensures driving safety


Constant power supply

No time limit for inspection
/Power supply module installed for continuous inspection

Front LED

Capable of functioning in low-light environments

Underwater location recognition

Underwater positioning program using DVL sensors


Control System

ROVINS is an operations and control system
for underwater robots.
  1. Control and inspection software exclusively for underwater robots
  2. Obstacle collision prevention system
  3. Underwater positioning program using DVL sensors
  4. Power supply module installed for continuous inspection
  5. NVR(Network Video Recorder)

Program Capture

01 360-degree ultrasonic sensor to prevent underwater collisions

  • Frequency : 750 kHz
  • Range : 0.75~50m

02 Backup Camera

  • Mounted LiDAR for SLAM with airframe positioning
  • Front camera to ensure driving safety
  • Front LED to cope with low light environment

Configuration

Specification

DiameterHeightWeight in AirMaximum speedThrust
600 x 800mm500mm53kg1.8Knot4.6kgf

Case of Use
